(when it was already calculated) are displayed
(when "Search" was executed).
— Search Search connected load cells.
Search for a new network and reset the load cell
data to the factory settings.
— View Serial number and current weigh of connected
load cells are displayed.
— Info The data for the selected Loading cell are
displayed.
— Assign load cells (serial number) are assigned to the
installation site.
— Calib Serial number and current weigh of connected
load cells are displayed.
— New Query window for new calibration: Corner
correction will be reset Yes, No
— Local gravity Enter the on-site gravitational acceleration
(Standard: Hamburg 9.81379 m/s
2
)
— Number of
platforms
Only for Pendeo Truck: Only shown if the
number of load cells is equal to 8.
— Number of
vessel feet
Only for Pendeo process: Enter the number.
— Max Enter maximum load:
0.000010<3000>9999998 <kg>, t, lb, g, mg,
oz
— Scale interval Enter verication interval (1 d): <1>, 2, 5, 10, 20,
50 displayed according to the decimal places at
Max and the weight unit.
— Dead load dead load: Weight of the empty scale
— CAL weight
Enter CAL weight: 0.0000109999998 <kg>, t,
lb, g, mg, oz
— Corner
correction
Platform 1, platform 2 (only shown if the
number of load cells is = 8).
O.k., when realized.
— Modify May be used only for minor changes (e.g.
changing the dead load). Otherwise, always use
[New]!
— Param Parameter settings
— Ambient
conditions
Select environmental conditions: Very stable,
stable, unstable, very unstable
— W&M Selection legal-for-trade mode: <none>, OIML,
NSC, NTEP
— Unbal.
Check deviat.
Average Deviation: The plausibility check is
activated when the average deviation is >0%.
Input: 0100 %
— Standstill time
Input of the standstill period: 0.01 s<0.50
s>2.0 s (The range depends on the measuring
time.)
— Standstill
range
Input of the standstill range: 0.00 d<1.00
d>10.00 d (The range depends on the
measuring time.)
7 Commissioning Transmitter Series PR 5220
EN-71 Minebea Intec
