Extruder Offset Calibration
XY Axis Offset Calibration
Click the "XY Offset" button.
Click the "General" button.
Fine-tune the XY axis to align the nozzle
center of the left extruder with the origin of
the XY axis. Click "Confirm Pos" to confirm
the position of the left extruder. Meanwhile,
the right extruder will move to the calibration
camera's position.
Click the "Start" button, and the left
extruder will move to the calibration
camera's position.
2
1
Click the "Save" button to save the XY
offset of the right extruder relative to the
left extruder.
Fine-tune the XY axis to align the nozzle
center of the right extruder with the origin
of the XY axis. Click "Confirm Pos" again to
confirm the position of the right extruder.
2
1
Tips:
Wipe the nozzle clean before calibration to avoid
any interference during the process.
13
