Mingda MD-600D - Printing Support

Printing Support
Printing size: 600 * 600 * 600mm
Selecting the MingDa 600D 0.4 nozzle (Dual)
5
3
4
2
1. On the left side of the interface, in the filaments column, click "+" to add another filament.
2. Choose and modify the filament information.
3. Then, select the "Support" section.
4. Check the "Enable support" option.
5. In the "Filament for Supports" option, choose the filament needed for supports.
6. Click "Slice plate" to preview.
6
Note: When printing models with supports, the printer will
automatically switch to Auto-park Mode.
In the printer interface:
By default, it is in "Auto-park
Mode"; select "Print."
Insert the U-disk. Choose the print file for printing.
1
we will take MD-600D as an example
