13
5.1 Heating
Controler
Check the controller for signs of overheating.
Melted plastics. Burned wirers. Burned con-
nectors.
Gently fell if some of the 4 connectors at the
controller have come loose.
Damaged or warned wirers. If some of the
wirers or 4 connectors to the controller look
damaged you can repair it as described in the
section “Replace receptor”.
Example of damaged controller.
You can see the plastic on the controller is
deformed from overheating coming from the
motor cables.
You can see the connector on the left hand
side have come loose from the controller.
Replace receptor:
For this operation you need to have the repair
kit: T-127-05-033
And the tool: TN 70 SE
