Functional requirements
Measurement of parking spaces
The following functional requirements apply
when measuring parking spaces:
– Driving forward: up to approx.
22 mph/35 km/h.
– Maximum distance to row of parked ve-
hicles: approx. 5 ft/1.5 m.
Suitable parking space
The following functional requirements apply
for suitable parking spaces:
Longitudinal parking:
– Minimum length of detected object, e.g.,
parking vehicle: approx. 3 ft/1 m.
– Minimum length of gap between two
objects: vehicle length plus approx.
2.6 ft/0.8 m.
– Minimum depth: approx. 5 ft/1.5 m.
Perpendicular parking:
– Minimum length of detected object, e.g.,
parking vehicle: approx. 3 ft/1 m.
– Minimum width of gap: vehicle width
plus approx. 2.3 ft/0.7 m.
– The minimum depth corresponds to your
vehicle's length.
The depth of perpendicular parking
spaces must be estimated by the driver.
Due to technical limitations, the system
is only able to approximate the depth of
perpendicular parking spaces.
Parking operation
The following functional requirements apply
when pulling into a parking space:
– The doors and cargo area are closed.
– The driver’s seat belt is fastened.
Leaving parking spaces
The following functional requirements apply
when pulling out of a parking space:
– The vehicle was parked using the Auto-
matic Parking Assistant, and an object
has been detected in the area around the
vehicle.
– The vehicle was manually parked in re-
verse, and objects have been detected
in the immediate vicinity of the vehicle.
The distance to a detected curb is at
least 6 inches/15 cm.
– The parking space is at least 2.6 ft/0.8 m
longer than the vehicle.
Displays
General information
The current status of the Automatic Parking
Assistant is shown on the Interaction Unit
and Head-up display,depending on vehicle
equipment.
Various icons are shown when selecting the
parking method.
The sequence of the displayed icons corre-
sponds to the prioritized parking option.
The direction of the arrow changes for the
icons for parking methods for driving out of
a parking space.
Icon Meaning
Reverse lengthwise parking,
right.
Reverse lengthwise parking,
left.
Reverse perpendicular parking.
Forward perpendicular parking.
