Minolta DiMAGE Z1 - Appendix; Troubleshooting

106
A
PPENDIX
Problem Symptom Cause Solution
The camera
will not work.
Nothing dis-
played on the
monitors.
The batteries are dead.
AA Ni-MH batteries are
inserted incorrectly.
The AC adapter is not
connected properly.
Replace batteries (p. 13).
Reinsert the batteries taking
care that the negative and pos-
itive terminals are oriented as
indicated on the inside of the
battery chamber door (p. 13).
Check that the adapter is con-
nected to the camera and a live
electrical outlet (p. 15).
The section covers minor problems with basic camera operation. For major problems or damage, or if
a problem continues to reoccur frequently, contact a Minolta service facility listed on the back cover
of this manual.
Shutter will
not release.
“000” is dis-
played on the
frame counter.
Memory card is full and
unable to store an image
at the image-quality or
image-size setting on the
camera.
Insert a new memory card (p.
16), delete some images (p.
31), or change the image-quali-
ty or image-size setting (p. 54).
No-card warn-
ing appears on
the monitors.
No memory card in the
camera.
Insert a memory card (p. 16).
APPENDIX
Troubleshooting
