131130
DIOPTER ADJUSTMENT
• When audio ON is selected, a tone will be heard when;
Focus is confirmed - 2 short beeps, except when the subject is
moving, or when AF-C is set.
Self-timer countdown - will beep slowly at first, then rapidly, and
finally a solid tone just before the shutter releases.
1. Open the control-panel door
and simultaneously press the
ADJ and CUSTOM buttons.
2. Turn either the front or rear
control dial to select audio ON
or OFF.
• The audio set display will
appear.
• The navigation display returns to the previous
display when the shutter-release button is
pressed partway down. appears when audio
is selected.
Your camera has the capability of producing an audio tone to let
you know when focus is confirmed and locked. It can also sound
when using the self-timer mode.
SETTING/CANCELLING THE AUDIO
ADDITIONAL FEATURES
• It may be easier to adjust if
the eyepiece cup is removed.
Farsighted users – turn the
dial clockwise.
Nearsighted users – turn the
dial counter-clockwise.
Turn the diopter-adjustment dial
until the focus frame appears
sharpest.
• For easier adjusting, before attaching the lens, look through the
viewfinder at a well illuminated blank wall or clear blue sky.
• If additional correction is needed, attach a Minolta Eyepiece Corrector
(optional accessory) to the camera’s eyepiece. There are 4 types
available for near sighted and 5 types for far sighted vision.
Turn the diopter adjustment dial to compensate the eyepiece for
near or far sighted vision problems. The adjustment range is from
–2.5 to + 0.5 diopters.
