-A1 controller E24 / E26 /1.18
-A2 control panel /1.28
-A3 key board /1.30
-G1 battery /1.2
-G2 on-board-charger /1.6
-K1 main contactor /1.10
-M1 drive motor /1.29
-M1.S1 thermal switch drive motor /1.30
-M1.S2 brake switch drive motor /1.37
-M1.Y1 brake drive motor /1.35
-M2 suction motor /1.26
-M3 conical brush motor left /1.25
-M3.S1 thermal switch brush motor left /1.27
-M4 conical brush motor right /1.25
-M4.S1 thermal switch brush motor right /1.27
-M7 water pump /1.19
-R1 speed giver /1.26
-S1 key switch /1.29
-S3 suction on /1.7
-S4 brush on /1.9
-S5 dead man switch left /1.30
-S6 direction switch /1.30
-S7 dead man switch right /1.25
-S11 spray tool on (OPTION spray tool) /1.33
-Y1 water valve /1.17
