60
Operation of the Monitor Wall
Changing the IP Address of a Multiviewer from the Monitor Wall
3Click OK.
Changing the IP Address of a Multiviewer from the Monitor Wall
With a Kaleido-X, or Kaleido-X16, you can set the IP address, system name, and other
parameters via a control panel on the monitor wall.
To change the IP address of the multiviewer from the monitor wall
1 Right-click anywhere on the monitor wall, point to Monitor wall, and then click System
configuration.
The System Configuration window appears.
2 Click the Ethernet tab.
3 Type the required Frame IP address, network mask, and gateway address in the
appropriate boxes.
4 Type the required addresses for all outputs.
5Click OK.
6 When prompted to restart the system to apply your changes, click Ye s.
The new configuration will become effective once the system restart has completed.
Notes
This section does not apply to the KMV-3901/3911, Kaleido-XQUAD,
Kaleido-MX, and Kaleido-Modular-X. For these multiviewers, you can
configure the network settings by using XAdmin, the Densité controller’s
local control panel (or a control panel in iControl, if available).
See
Configuring a Multiviewer’s IP Settings on page 395, or refer to the Quick
Start Guide for your multiviewer, for details.
In the case of a Kaleido-IP, changing the multiviewer’s network settings from
the monitor wall is not yet supported.
