82
Appendix A: Specifications
12.4 FX-2000 Specifications
Table 24 FX-2000 System Modules and Annunciator Specifications
FX-2000 System Modules and Annunciators
ALC-198S Single Intelligent Analog Loop Module One Analog Loop capable of monitoring 99
Sensors and 99 Modules or 99 Advanced
Protocol (AP) devices and 99 AP Modules.
Power limited 22 VDC, 400 mA max
max loop resistance 40
Current Consumption Standby: 50 mA / Alarm: 60 mA
ALC-396S Dual Intelligent Analog Loop Module Two Analog Loops capable of monitoring 198
Sensors and 198 Modules or 198 Advanced
Protocol (AP) devices and 198 AP Modules.
Power limited: 22 VDC, 400 mA max, max loop resistance 40
Current Consumption standby:50 mA / alarm: 60 mA
ALC-H16 Loop Controller Module Provides connection for adding up to 16 FA-
1000 style adders DM-1008A, SGM-1004A
and RM-1008A.
Current Consumption standby: 35 mA / alarm: 50 mA
SGM-1004A NAC Signal Adder Module Four Class B or A (Style Y or Z) NAC circuits;
configurable as strobes or audibles. Terminals
are labelled "IND".
Power Limited: 24 VDC unfiltered max. 1.7 amps @ 49C per
circuit
Current Consumption standby: 60 mA / alarm: 258 mA
RM-1008A
(resistive loads)
Relay Adder Module Must be connected to a listed power limited
source of supply. Terminals are labelled "RLY".
Eight fully configurable Form C NAC.
Form C, 1 amp., 28 VDC (resistive loads)
Current Consumption standby: 25 mA / alarm: 150 mA
PR-300 Polarity Reversal and City Tie Module Supervised city tie--not power limited
24VDC unfiltered, 210 mA max., Trip coil: 14
ohms.
Terminals are labelled "City Tie".
Polarity reversal power limited
Terminals are labelled "Polarity Reversal".
24VDC open
12VDC @ 3.5 mA, 8 mA max. (shorted)
Current Consumption standby: 35 mA / alarm: 300 mA
