Appendix A: Specifications
DM-1008A Detection Adder Module Eight supervised Class B (Style B) or four
Class A (Style D) NAC circuits; fully
configurable. Terminals are labelled "INI". NAC
circuits are Compatibility ID "A".
Current Consumption standby: 80 mA
alarm: 1 zone active: 125 mA
2 zone active: 170 mA
4 zone active: 275 mA
6 zone active: 370 mA
8 zone active: 465 mA
FDX-008W Fan Damper Display Module 24V DC nominal, range of 20 to 39V DC.
Interconnects via one ribbon cable to P2 of
previous display module. Provides eight
configurable output circuits or fan damper
controls.
Current Consumption standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
FDX-008WKI Fan Damper Display Module with
Keyswitch
24V DC nominal, range of 20 to 39V DC.
Interconnects via one ribbon cable to P2 of
previous display module. Provides eight
configurable output circuits or fan damper
controls, 1 output controlled via keyswitch.
Current Consumption standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
RAX-1048TZDS Adder Annunciator Chassis 48 Display Points and 48 trouble points.
Interconnect via one ribbon cable to RAM-
1032(TZ) or to previous RAX-1048(TZ).
Annunciation of up to 48 additional points (with
trouble annunciation on the TZ version).
Current Consumption standby: 22 mA
alarm: 1 zone LED active: 26 mA
2 zone LED active: 30 mA
3 zone LED active: 35 mA
4 zone LED active: 39 mA
48 zone LED active: 262 mA
IPS-2424DS Programmable Input Switches
Module
Current Consumption standby: 5 mA
alarm: 22 mA maximum
Table 24 FX-2000 System Modules and Annunciator Specifications (Continued)
