MiTAC E-8590 - 9 Spare Parts List

199
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Part Number Description Location
442671200004 AC ADPT ASSY;19V/4.74A,DELTA,817
361400003030 ADHESIVE;ABS+PC PACK,G485,CEMIDA
361400003005 ADHESIVE;HEAT,TRANSFER,HTA-48(W)
346673500014 AL FOIL;TOUCH PAD,T/P SHIELD,WEA
442673500001 BATT ASSY;14.8V/4.0AH,LI,MSL,WEA
441503200201 BATT ASSY;LI,8CELLS/4.0A,PANASON
541350320201 BATT KIT;WEASEL/14.8V,4AH
338536010006 BATTERY;LI,3.6V/2.0AH,18650,PANA
340673500011 BEZEL ASSY;TEAC DV-28E,WEASEL
242670800113 BFM-WORLD MARK;WINXP,7521N
342672200010 BRACKET;CD-ROM,8500
342673500004 BRACKET;LCD,L,WEASEL
342673500003 BRACKET;LCD,R,WEASEL
344673500015 BUTTON;SCROLL T/P,WEASEL
272075103702 CAP;.01U ,50V,+80-20%,0603,Y5V,S C167,C186,C224,C503,C544
272075103401 CAP;.01U ,CR,50V ,10%,0603,X7R,S PC22,PC525
272075103401 CAP;.01U ,CR,50V ,10%,0603,X7R,S PC18,PC19,PC30,PC506,PC
9
272073223401 CAP;.022U,CR,25V ,10%,0603,X7R,S C7,C8
272072473401 CAP;.047U,16V ,10%,0603,X7R,SMT PC50,PC63
272075104701 CAP;.1U ,50V,+80-20%,0603,Y5V,S C1,C100,C101,C103,C108,C
1
272075104701 CAP;.1U ,50V,+80-20%,0603,Y5V,S C502,C503,C506,C507,PC1,
P
272075104701 CAP;.1U ,50V,+80-20%,0603,Y5V,S
272072104402 CAP;.1U ,CR,16V,10%,0603,X7R,SM C585,PC17
272072104402 CAP;.1U ,CR,16V,10%,0603,X7R,SM C1,C4,C13,C16
272005104404 CAP;.1U,CR,50V,10%,0805,SMT PC15,PC16,PC46,P C47
Part Number Description Location
272072224402 CAP;.22U ,16V ,10%,0603,X7R,SMT C130,C520,C632,C633,C634
272002474401 CAP;.47U ,CR,16V ,10%,0805,X7R,S
272030102401 CAP;1000P,2KV,10%,1808,X7R,SMT C530,C557,C559,C568,C571
272075102701 CAP;1000P,50V ,+/-20%,0603,X7R,S C110,C135,C238,C239,C29,
C
272075102403 CAP;1000P,CR,50V,10%,0603,X7R,SM PC28,PC30,PC39,PC507,PC
5
272075102403 CAP;1000P,CR,50V,10%,0603,X7R,SM C1,C509,PC25,PC27,PC33,P
272075101701 CAP;100P ,50V ,+ -10%,0603,NPO,S C232,C233
272075101302 CAP;100P ,CR,50V,5%,0603,NPO,SMT C11
272010101302 CAP;100P,2KV,5%,1206,NPO,SMT,onl C15
272431107514 CAP;100U,CD,2.5V,20%,7343,SP-CON PC25,PC29,PC42,PC69
272075100302 CAP;10P ,CR,50V ,5%,0603,NPO,SM C211,C212,C213,C214,C532
272021106501 CAP;10U ,10V ,20%,1210,X7R,SMT PC49,PC51,PC59
272011106701 CAP;10U ,10V,+80-20%,1206,Y5V,S C10,C175,C181,C197,C20,C
2
272012106701 CAP;10U ,16V ,+80-20%,1206,Y5U, C172,C190,C95,PC14,PC41,
P
272023106501 CAP;10U ,25V ,20%,1210,Y5U,SMT C215,PC34,PC4,PC5,PC8
272023106501 CAP;10U ,25V ,20%,1210,Y5U,SMT PC2,PC507
272073151301 CAP;150P ,CR,25V,5% ,0603,NPO,SM C134,C516
272073151301 CAP;150P ,CR,25V,5% ,0603,NPO,SM PC12
272431157509 CAP;150U,KOCAP,6.3V,20%,7343,SMT PC511,PC523
272071105701 CAP;1U ,CR,10V ,80-20%,0603,Y5 C118,C119,C178,C218,C219
272071105701 CAP;1U ,CR,10V ,80-20%,0603,Y5 C501,C508
272071105701 CAP;1U ,CR,10V ,80-20%,0603,Y5 C9
272001105402 CAP;1U ,CR,10V,10%,0805,X5R,SM C6
272072105702 CAP;1U ,CR,16V,+80-20%,0603,Y5
272002105402 CAP;1U ,CR,16V,+80-20%,0805,Y5 P C35,PC52
9. Spare Parts List -1
