MiTAC E-8590 - System Hardware

5
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
1.2 System Hardware Parts
Item
Description
CPU
Intel Desktop Pentium 4 (Northwood) mPGA478
2G,2.2G,2.26G,2.4G,2.5G,2.53G,2.6G,2.66G,2.8G
Intel Desktop Celeron mPGA478 1.7G,1.8G,1.9G
Core logic
VIA VT8703A support 400MHz /533Mhz FSB + VT8235
L2 Cache
512KB for Pentium 4 on Die
128KB for Celeron on Die
System BIOS
512KB Flash EPROM
Insyde -Includes System BIOS , VGA BIOS, and plug & Play capability, ACPI
Memory
-Two 184 pin DDR-DIMM socket for memory expansion
-Support PC2100 / PC1600 with SPD
Video Controller
Integrate S3 Savage8
Support MPEG-2 30fps, 8.5MB/s capability
1024x768 (24bit color by dithering) XGA. CMOS 18+18 bits interface
and 1600x1400 (24bit color) resolution for CRT
- Support LCD/CRT simultaneous display only
Video Memory
8/16/32MB share system SDRAM, default 8Mbyte
Clock Generator
ICS 950902
REALTEK RTM360-519R
PCMCIA
Cardbus Controller: ENE CB710
one type II slots CardBus / no ZV port support/ no wakeup at S3
Power switch: TI TPS221 or ENE CP-2211
Memory Card
Reader
Integrate in CB710
Support Smart Media, SD/MMC and Memory Sticker 3.3v only
USB 2.0
USB 2.0 Controller integrate in VT8235
IEEE1394
IEEE1394 OHCI Controller: VIA VT6306
No wakeup at S3
Not support bridge mode when system off
Audio System
AC97 CODEC: Realtek ALC202
Power Amplifier: TI TPA1517 3W+3W
Modem
ASKey 56Kbps(V.90, worldwide) MDC Modem
LAN Phy
VIA VT6103 10baseT/100 baseT – Ethernet PHY
