1.5 Peripheral Components
1.5.1 LCD Panel (1)
Mitsubishi / ADI AU optical
Product Name TFT XGA (1024x768) TFT XGA (1024x768)
Model Name
AA150XC01 M150XN05-1
Mechanical Specifications
Display size 38.1 (15") Diagonal cm 38.1 (15") Diagonal cm
Active area 304.1(H)×228.1(V) mm 304.1(H)×228.1(V) mm
Pixel format 1024(H)×768(V) pixel
(1 pixel = R+G+B dots)
1024(H)×768(V) pixel
(1 pixel = R+G+B dots)
Pixel pitch - 0.297(H)×0.297 (V) mm
Pixel configuration R,G,B vertical stripe R,G,B vertical stripe
Display mode Normally white TN
Normally white TN
Unit outline dimensions *1 326.0(W)×255(H)×15.5max.(D)
mm
326(W)×249.0(H)×12.05max.(D)mm
Number of Color 16..7M(8 bits/color) 262,144 colors (6 bit for RGB)
Brightness 300 cd/m
2
(Typ) 250 nit (typ) at 8mA
View Angle -75 to 75 (H) , -60 to 50 (V) -60 to 60 (H) , -60 to 40 (V)
Mass 1350 g 1100 g
Surface treatment Anti-glare and hard-coating 3H Anti-glare and hard-coating 3H
TFT-LCD CMOS 24+24 interface
Using connector IL-FHR-BF40S-HF (JAE)
IL-FHR-BF36S-HF (JAE)
FH-12-30S-0.5SH (Hirose)
FH-12-45S-0.5SH (Hirose)
Corresponding connector - -
