1.7 Appendix
1.7.1 VT8235 GPI Definitions (1)
Signal
Name
POWER
PLANE
MUX WITH
Output/OD
Default
Function
Value
GPIO_DIR
Defaults
E-Note GPIO Setting
GPI0 Resume /TTL GPI0 Input I
N/A
GPI1 Resume /TTL GPI1 Input I
N/A
GPI2 Resume EXTSMI /TTL EXTSMI Input I
EXTSMI#
GPI3 Resume RING# /TTL RING# Input I
CARD_RI#
GPI4 Resume LID# /TTL LID# Input I
LID#
GPI5 Resume BATLOW# /TTL BATLOW# Input I
N/A
GPI6 Resume AGPBZ /TTL AGPBZ Input I
PME#
GPI7 Resume REQ5 /TTL GPI7 Input I
N/A
GPIO8 GPO8 /TTL GPI8 Input I
M_ID0
GPIO9
GPO9/VRDPSL
P
/TTL GPI9 Input I
M_ID1
GPIO10 GPO10 /TTL GPI10 Input I
M_ID2
GPIO11 GPO11 /TTL GPI11 Input O
N/A
GPIO12 GPO12 /TTL GPI12 Input O
EN_BL
GPIO13 GPO13 /TTL GPI13 Input O
SPKR_MUTE#
GPIO14 GPO14 /TTL GPI14 Input O
N/A
GPIO15 GPO15 /TTL GPI15 Input O
N/A
GPI16 Resume INTRUDER# /TTL INTRUDER# Input I
INTRUDER#
GPI17 Resume CPUMISS /TTL CPUMISS Input I
N/A
GPI18
AOLGPI/THR
M#
/TTL AOLGPI Input I
THRM#(INPUT)
GPI19 IORDY /TTL IORDY Input I
N/A
GPIO20
GPI20/SDIN2/P
CS0#/VGATE
/OD SDIN2 Input O
N/A
