95
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
1.5.3 CD-ROM / CDR-RW / COMBO Drive (5)
CD Connector Pin Assignment ( CD side JAE KX15-50KLD)
Pin
No.
Symbol I/O Pin
No.
Symbol I/O
49 Vender unique 50 Vender unique
I:Input,
O:Output,
I pu: pull-up Input,
I pd: pull down input,
O od: oper-drain Output,
O 3s: 3 state output
1.5.4 Keyboard
Internal keyboard: Compatible KU keyboard layout (105 keys)
