Part Number Description Location
284109248001 IC;ICS9248-193,SYSTEM CLK,SSOP,4 U509
286300811001 IC;IM811,MICROPWR VOL,SOT23-4 U7
284500086001 IC;LM86,TEMPERATURE MTR,SO8 U510
286100393004 IC;LMV393,DUAL COMPARTOR,SSOP,8P PU2
286302951015 IC;LP2951ACM,VOLTAGE REGULAT OR,S U13
286317097001 IC;LTC1709EG-7,PWM CTRL,SSOP ,36 PU9
286303707001 IC;LTC3707,PWM SWITCH REG,SOOP,2 PU16
286300809002 IC;MAX809S,RESET CIRCUIT,2.9V,SO U16
286301414001 IC;MM1414,PROTECT ION,TSOP-20A,PR
286300965001 IC;OZ965R,CCFL CTRL,TSSOP16,O2 U1
286309701001 IC;RT9701,POWER DISTRI SW,SOT23- U501,U502
286381250001 IC;S-81250,DECECTOR,SOT-89,PRC
286300431014 IC;SC431LCSK-.5,.5%,ADJ REG,SOT2 PQ3
286300431014 IC;SC431LCSK-.5,.5%,ADJ REG,SOT2 PQ1
283767350002 IC;SDRAM,2M*16*4-133,TSOP,54P,WE U10,U11,U504,U505,U506,
U
286300055001 IC;TC55,3.3V,250mA,REG.,SOT89 U15
286300594001 IC;TL594C,PWM CONTROL,SO,16P P U4
286100212001 IC;TPA0212,AMPLIFIER,TSSOP,24P,S U516
284506103002 IC;VT6103,LAN-PHY,SSOP,48P ,SMT U508
284508231002 IC;VT8231,P CI/ISA,BGA,376P ,SMT U514
284508362001 IC;VT8362,NORTHBRIOGE,BGA,552P U501
273000120128 INDUCTOR;10nH,10%,0805,SMT L11,L13,L501,L502,L503,L5
0
273000990012 INDUCTOR;10UH,CDRH127,SUMIDA,SMT PL503
273000990031 INDUCTOR;10UH,CDRH127B,SUMIDA,SM P L502
273000990024 INDUCTOR;47uH,CDRH127,SUMIDA,SMT PL501
Part Number Description Location
346673500008 INSULAT ION;DIMM,WEASEL
346600000412 INSULATOR/ADHESIVE;FIBER/W204,T=
346600000414 INSULATOR/ADHESIVE;FIBER/W204,T=
346669600062 INSULATOR;1,BATTERY ASSY,FUSE,RA
346503100005 INSULATOR;5,BATTERY ASSY,7521Li
345503400002 INSULATOR;BATT ASSY,FOR PCB AND
346503200202 INSULATOR;BATT ASSY,ONE ROUND,BL
346503200203 INSULATOR;BATTERY ASSY,PCB,W12L1
346673500004 INSULATOR;CHANGE BD,WEASEL
346503200201 INSULATOR;FOR 2CELL/2ADHESIVE,WE
346670500005 INSULATOR;HDD,TETRA
346673500010 INSULATOR;HEATSINK,WEASEL
346669900004 INSULATOR;INVERTER,7170
346673500001 INSULATOR;MB,WEASEL
346673500015 INSULATOR;MDC,T/P SHIELD,WEASEL
346673500006 INSULATOR;TOUCHPAD,WEASEL
346673500003 INSULATOR;TRANS BD,WEASEL
531020237461 KBD;87,FR,K982318Z1,WEASEL
451673500010 LABEL KIT;AMD-DURON,CPGA,EOS,WEA
242600000145 LABEL;10*10,BLANK,COMMON
242600000380 LABEL;10*8MM,BIOS,HI-TEMP 260
242662300009 LABEL;25*10MM,3020F
242662300009 LABEL;25*10MM,3020F
242600000434 LABEL;25*6MM,COMMON
242668300017 LABEL;4*3MM,HI-TE
