8590 MAINTENANCE
8590 MAINTENANCE
Smart Card Interface
Compliant with PC/SC Specification 1.0
Support ISO7816 T=0 and T=1 asynchronous communication protocols
Two power enable pins to support 5V and 3V smart cards
Four programmable card clock frequencies
Support all possible combination of F and D parameters
One traffic LED pin
Secure Digital interface
Compliant with SD Memory Card Specification Version 1.0
Support 4 Parallel data lines
Support DMA data transfer between SD cards interface and system memory to minimize system overhead
Has an optional reference clock source to control the operating clock frequency of SD card
Up to 10Mbyte/sec Read/Write rate when the optional reference clock source is used
Contains 16 Byte of data buffer to regulate the data flow between PCI interface and the SD card interface
Support Card Bay PC card interface
