54
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
Meets Microsoft PC99 & WLP 2.0 audio requirements
Power management and enhanced power saving features
2 GPIO pins
No external crystal/clock required
14.318MHz/48MHz 24.576MHz PLL saves crystal
DC Voltage volume control
Auxiliary power (VAUX ) to support Power Off CD function
Power support: Digital: 3.3V; Analog: 3.3V/5V
Standard 48-Pin LQFP Package
18-bit Stereo full-duplex CODEC with independent and variable sampling rate
18-bit ADC and 20-bit DAC resolution
Four analog line-level stereo inputs with 5-bit volume control: LINE_IN, CD, VIDEO, AUX
High quality differential CD input
Two analog line-level mono input
PC_BEEP,PHONE_IN
Supports double sampling rate (96KHz) of DVD audio playback
Two software selectable MIC inputs
