64
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
1.2.13 LAN: VT6103 10Base-T/100Base-TX Ethernet PHY
The VT6103 is a Physical Layer device for Ethernet 10BASE-T and 100BASE-TX using category 5 Unshielded,
Type 1 Shielded, and Fiber Optic cables. This VLSI device is designed for easy implementation of 10 / 100 Mb/s
Fast Etherent LANs. It interfaces to a MAC through an MII interface ensuring interoperability between products
from different vendors.
Product Features
Single Chip 100Base-TX/10Base-T Physical Layer solution
Dual Speed – 100/10 Mbps
Half And Full Duplex
MII Interface to Etherent Controler
MII Interface to Configuration & Status
Optional Repeater Interface
Auto Negotiation : 10/100, Full/Half Duplex
Meet All Applicable IEEE 802.3, 10Base-T and 100Base-Tx Standards
On Chip Wave Shaping – No External Filters Required
Adaptive Equalizer
Baseline Wander Correction
