80
LCD PC E
LCD PC E
-
-
8590 MAINTENANCE
8590 MAINTENANCE
S6 mechine off : LED off
S3 Suspend to RAM: LED amber
S4/S5 (Hibernation and Soft off) : LED red
S0 System on: LED Green
1.4.4.2 Three LED Indicators Above Keyboard:
From left to right that indicates NUM LOCK, CAPS LOCK and SCROLL LOCK.
1.4.5 Fan Power On/off Management
FAN is controlled by VT1211 SuperIO with hardware monitor to sense CPU temperature and PWM control fan
speed. Fan speed is depended on CPU temperature. Higher CPU temperature faster Fan Speed.
PWM Fan Full Speed Temperature Value
PWM Fan High Speed % Duty Temperature Value
1.4.4.1 Three LED Indicators at Top Side:
From left to right that indicates, AC POWER, CD active and Hard Disk active.
POWER STATUS
