Mitel IP Phone User Reference Guide Release 4.1
96
Connect and configure the headset
To connect the headset to the Mitel 5340, 5224/5324 or 5212/5312 IP phone,
follow these steps:
1. Plug the headset into the headset jack on the back of the set.
2. Remove the handset from the cradle. You can hook it over the top of the set
cradle.
3. If using a Mitel 5340 or 5224/5324 IP phone, press the DIR softkey, then the
QUIT softkey to take the phone to an on-hook (or idle) state.
If using a Mitel 5212/5312 IP phone, press the
key, then press the
key to take the phone to an onhook (or idle) state.
Answer a Call with the headset
To answer a call while using the headset, press the Line Appearance key or the
ANSWER softkey.
End a Call with the headset
To end a call while using the headset on the Mitel 5224/5324 or 5340 IP phone,
press the END softkey
To end a call while using the headset on the Mitel 5212/5312 IP phone, press the
key.
Mute the headset
To mute the microphone, press and hold the control switch if it has one.
Make a call with the headset
To make a call while using the headset, press a Line Appearance key and dial
the number. line. You can also use dial, directory dial, and speed dial features.
See the section for making a call for your phone model in this guide.
Switch to the handset
To divert the operation back to the handset, the user can either
• Disconnect the headset from the phones jack or
• Use an external headset adapter box which has a dedicated
headset/handset switch.
Using a Programmable Key Module
A Programmable Key Module (PKM) provides additional memory keys to those
provided on your phone. The system supports the Mitel 5412 PKM which
provides an extra 12 additional memory keys and the Mitel 5448 PKM which
provides an additional 48 memory keys. If required you can have up to two 5448
PKM units on one phone.
The PKMs can be attached to Mitel 5224 or 5324 IP phones.
