Keys, display, and menu guidance
Mitel 6867 SIP / Mitel 6869 SIP 13
eud-1664/2.0 – R6.0 – 06.2018
No
.
Key Description
1 Handset
2Display color screen:
• top left: line number, name
1)
.
• top right: status display (display symbols).
• bottom right: status notifications.
• Middle: Display, depending on phone status.
3 Message LED color and status signal a specific event.
4
Phone book key
(Mitel 6867 SIP only)
Calling up the directory lookup.
5 Navigation key with
selection key
Four directional keys (up, down, left, and right) on
the navigation cluster that can be used to navigate
through the various applications and settings
menus. The centre key acts as a Select button.
Horizontal navigation
keys
• Switching between the display in idle state and
line selection.
• Navigating in the options list.
Vertical navigation keys Navigating in the sub-menus of the options list.
Selection key • Selecting a menu item.
• Confirming settings.
6
Deflect key
(Mitel 6867 SIP only)
Transferring a call.
7
Conference key
(Mitel 6867 SIP only)
Setting up conference calls.
8 Call lists key Calling up the call list menu:
• unanswered
• answered
• redial list
9 Redial key Using the phone number last dialed.
