Mitel 6869 SIP - Display Symbols

16 Mitel 6867 SIP / Mitel 6869 SIP
eud-1664/2.0 – R6.0 – 06.2018
Keys, display, and menu guidance
Note: The Mitel 6867 SIP and Mitel 6869 SIP phones have removable key caps.
If you change the position of a function on your phone, you can change the
function to the corresponding function key using the Self Service Portal.
An overview over interchangeable functions can be found in chapter
"Available keys", page 97
.
Display symbols
2)
Use the headset connection for headsets only. Connecting another device may cause dam-
age to your phone and void your warranty.
Status bar
Missed calls
New voice message
Note: If there are more than nine missed calls, the number of missed calls are dis-
played as exclamation mark. The exclamation mark is also displayed in special
circumstances, for example, if there is a voice mail message or a notification /
call back request.
Headset connected
Unconditional call forwarding activated
Do not disturb (if busy)
Operator queue
USB deactivated
Note: The icon USB deactivated is displayed when the phone is powered using Power
over Ethernet or if one or more expansion key modules are connected. In order
to be able to use the USB connection, you must power your phone using PoE+
or the power supply available as an option.
Call recording activated
Presence state: Available (default)
Presence state: Meeting
Presence state: Absent
