Keys, display, and menu guidance
Mitel 6867 SIP / Mitel 6869 SIP 15
eud-1664/2.0 – R6.0 – 06.2018
Bottom softkeys S1-S24
(Mitel 6869 SIP)
Five freely configurable keys on which a total of
24 functions or call numbers can be configured.
Default functions are automatically set by the
MiVoice Office 400 communication system. You
can configure additional functions or change the
default functions. If more than five functions or call
numbers are configured, the fifth key is used to
switch levels. Every fifth function or call number is
accessible at the next level.
21 Rear:
• Connection for expansion key module.
• Connection for power supply.
• Connection for USB 2.0.
• GigE dual connection for PC and LAN; Connection for Power over Ethernet
(PoE), class 2 (Mitel 6867 SIP only), class 3 (Mitel 6869 SIP only).
• Connection for headset.
• Combined four-pin module connection with DHSG/EHS headset connec-
tion
2)
.
• Connection for wall mounting.
• Connection for magnetic keyboard.
22 Info key Accessing the phone status of a contact on the
busy lamp field (see "Using the busy lamp field
key", page 76).
23 Speaker
24 Programmable keys T1-
T20 with LED
(Mitel 6867 SIP)
Six freely configurable keys that can be set up for
various functions, call numbers, or busy lamp
fields. If more than six functions, call numbers, or
busy lamp fields are configured, the bottom key is
used to switch levels. Every sixth function is
accessible at the next level. A LED is located next
to each function key signaling the functional state.
Left/right programma-
ble keys T1-T44 with
LED
(Mitel 6869 SIP)
Twelve freely configurable keys that can be set up
for various functions, call numbers, or busy lamp
fields. If more than twelve functions, call numbers,
or busy lamp fields are configured, the bottom key
is used to switch levels. Every twelfth function is
accessible at the next level. A LED is located next
to each function key signaling the functional state.
1)
depending on configuration
No
.
Key Description
