Keys, display, and menu guidance
Mitel 6867 SIP / Mitel 6869 SIP 27
eud-1664/2.0 – R6.0 – 06.2018
Keypad Mitel K680
You can connect a magnetic keypad to your phone in order to simplify text
input. The Mitel K680 has the following properties:
• The keyboard can be connected and removed magnetically.
• The keyboard connection is available in three versions:
– QWERTY (Mitel K680 QY),
– QWERTZ (Mitel K680 QZ),
– AZERTY (Mitel K680 AY).
• The phone supplies power to the keypad.
Notes: • Mitel K680 settings in the menu are only available if a Mitel K680 is con-
nected.
• The Mitel K680 is a local module and is not controlled via the MiVoice
Office 400 communication system.
No
.
Key Description
1 A1-A84 function keys
(3 key levels, 28 keys
each)
Freely configurable keys. An LED is located next
to each function key signaling the functional state.
2 Function key for level 1,
2, 3
Call up the desired level.
