INNLINE IP Installation guide Chapter 1: Installation
2
Preinstallation information
The InnLine IP voice mail system requires an operating environment that meets the
following conditions:
• The temperature is between 55 and 75 F, humidity non-condensing.
• The UPS is connected to a 20-amp, two-outlet AC power source.
• The modem line connecting to the InnLine IP system is terminated to an RJ-11
phone jack.
Opening and verifying system components
Before installing the system, verify that all the components are present.
With all systems, you should find:
• 1U server
• UPS (uninterruptible power system)
• AC Power cord
• UniKey PRO Mini Software key (already connected to the system internally)
• USB Keyboard
• USB mouse
• USB Flash drive for back-ups (already connected to the system internally)
• USB modem (if optionally purchased)
• VGA monitor
• RJ-45 CAT5 network cable
•
1
Dialogic Media Gateway(s) and NETGEAR switch
• System documentation
Some systems may come with additional items. If you feel that anything is missing,
contact Connected Guests at the number shown on the front of this manual.
1
This hardware is included if the PBX does not have a native SIP integration with InnLine IP
