3.5.1 ELU33, ELU34, ELU31/4 AND TLU80 CABLE STRUCTURE
Figure 20: Front view
Note: ELU34 has to have individual 0 activated as the first individual and removed as
the last individual, or else the communications with the board will fail.
Table 7 Color Coding in 32 Pair Cable for ELU33, ELU34 and ELU31
Front LED
Front
connector
A
1
2
3
4
5
6
1
7
8
9
10
11
12
2
13
14
15
16
17
18
3
B C D
Pair Core Color Bundle Connector Pair Core Color Bundle Connector
1 a White D18 21 a White D9
b Blue C18 b Blue C9
