3.4.1 CONNECTING KEYBOARD AND MONITOR
This section describes how to connect keyboard and monitor to multiple servers.
Table 6 Keyboard and Monitor Package
Servers and ASU boards are connected to the keyboard and monitor by using the USB
interface adapter, see Figure 17: Connecting Keyboard and Monitor on page 25.
Note: A Keyboard-Video-Mouse (KVM) switch expansion (KDU 137 346) must be
used if more than eight servers are to be connected to the keyboard and
monitor.
Pos. Title/Function Product Number
A
MX-ONE
TM
Keyboard and Monitor Package
XX / KDT 252 01/1
B Rack Mount Server KVM Switch (8 ports) KDU 137 390
Rack Mount Server KVM Switch Expansion
(8 ports)
KDU 137 346
C USB Interface Adapter KDU 137 395
D Patch Cables RJ45 - RJ45 (included in KDU 137 390 and KDU 137
346)
