Mitel MX-ONE - 3.5.4 ELU26 and TLU79 cable structure; 3.5.5 MGU and MGU2 cable structure

21/1531-ASP11301 Uen B3 2016-02-17 34
C
ABLING
3.5.4 ELU26 AND TLU79 CABLE STRUCTURE
Table 14 Color Coding in Cable for ELU26 and TLU79 (TSR 491 414)
3.5.5 MGU AND MGU2 CABLE STRUCTURE
Table 15 Color Coding in Cable for MGU E1/T1 connection (TSR 482 0211/xxx)
2 A Orange/White 1 Rx+
B Orange 2 Rx-
3 A Green/White 3 Shield
B Green 6 Shield
4 A Brown/White 7 NC
BBrown 8 NC
Pair Core Color Pinn No. Description
Pair Core Color Connector Description
1 A White C6 Individual 0
TX+, TX-
BBlue D6
2 A White A6 Individual 1
TX+, TX-
BOrange B6
3 A White C5 Individual 0
RX+, RX-
BGreen D5
4 A White A5 Individual 1
RX+, RX-
BBrown B5
6 A Red C4 Individual 2
TX+, TX-
BBlue D4
7 A Red A4 Individual 3
TX+, TX-
BOrange B4
8 A Red D3 Individual 2
RX+, RX-
BGreen C3
9 A Red B3 Individual 3
RX+, RX-
BBrown A3
Pair Core Color Pinn No. Description
1 A Blue/White 5 Tx+
BBlue 4 Tx-
2 A Orange/White 1 Rx+
B Orange 2 Rx-
3 A Green/White 3 Shield
B Green 6 Shield
4 A Brown/White 7 NC
BBrown 8 NC
