INSTALLING BOARDS AND CABLING
29 21/1531-ASP11301 Uen B3 2016-02-17
Table 8 Front interface
Signal Description
Connector
row
La10, Lb10 - incoming 4-wire line (ind 0) D17, C17 (3D5, 3C5)
- 2-wire line (ind 0)
La20, Lb20 - outgoing 4-wire line (ind 0) A17, B17 (3A5, 3B5)
La11, Lb11 - incoming 4-wire line (ind 1) D15, C15 (3D3, 3C3)
- 2-wire line (ind 1)
La21, Lb21 - outgoing 4-wire line (ind 1) A15, C15 (3A3, 3B3)
La12, Lb12 - incoming 4-wire line (ind 2) D12,C12 (2D6, 2C6)
- 2-wire line (ind 2)
La22, Lb22 - outgoing 4-wire line (ind 2) D13, C13 (3D1, 3C1)
La13, Lb13 - incoming 4-wire line (ind 3) D10, C10 (2D4, 2C4)
- 2-wire line (ind 3)
La23, Lb23 - outgoing 4-wire line (ind 3) A10, B10 (2A4, 2B4)
M0 - M-lead; transmitter (ind 0) C18 (3C6)
E0 - E-lead; receiver (ind 0) D18 (3D6)
A0 - A-lead; transmitter for blocking (ind 0) B16 (3B4)
BLK0 - BLK; receiver for blocking (ind 0) A16 (3A4)
R00 - Return wire (ind 0) C9 (2C3)
R10 - Return wire (ind 0) D9 (2D3)
R20 - Return wire (ind 0) B8 (2B2)
R30 - Return wire (ind 0) A8 (2A2)
M1 - M-lead; transmitter (ind 1) C16 (3C4)
E1 - E-lead; receiver (ind 1) D16 (3D4)
A1 - A-lead; transmitter for blocking (ind 1) B14 (3B2)
BLK1 - BLK; receiver for blocking (ind 1) A14 (3A2)
R01 - Return wire (ind 1) C8 (2C2)
R11 - Return wire (ind 1) D8 (2D2)
R21 - Return wire (ind 1) C7 (2C1)
R31 - Return wire (ind 1) D7 (2D1)
M2 - M-lead; transmitter (ind 2) C14 (3C2)
E2 - E-lead; receiver (ind 2) D14 (3D2)
A2 - A-lead; transmitter for blocking (ind 2) B11 (2B5)
BLK2 - BLK; receiver for blocking (ind 2) A11 (2A5)
R02 - Return wire (ind 2) B6 (1B6)
R12 - Return wire (ind 2) A6 (1A6)
R22 - Return wire (ind 2) C6 (1C6)
R32 - Return wire (ind 2) D6 (1D6)
M3 - M-lead; transmitter (ind 3) C11 (2C5)
E3 - E-lead; receiver (ind 3) D11 (2D5)
A3 - A-lead; transmitter for blocking (ind 3) B9 (2B3)
BLK3 - BLK; receiver for blocking (ind 3) A9 (2A3)
