M800W/M80W Series Connection and Setup Manual
2 General Connection Diagram
9
IB-1501268-K
2.2.3 M80W, Non-Windows-based Display (8.4-type /10.4-type /15-type)
(Note 1) For information on how to connect the drive unit, refer to the drive unit's manual.
(Note 2) For the connection of machine operation panel, refer to the chapter "Connection of Machine Operation Panel".
(Note 3) When connecting a remote I/O unit to the 3rd RIO channel, insert it between the control unit and operation
panel I/O unit.
(Note 4) There is no need to connect a terminator R2-TM to the graphic control unit.
(Note 5) For the 8.4-type display unit, TP connector is not used.
(Note 6) When the handle of handy terminal is used, connect ENC connector of G430 cable to MPG connector of the
operation panel I/O unit.
Because the pin assignment of ENC connector of G430 is different from that of MPG connector of the
operation panel I/O unit, conversion is required.
The conversion cable needs to be prepared by the MTB.
SIO
1ch:J030
2ch:J031
2ch
RS232C
SKIP
RIO2
SD
RIO3
GDI
LAN
J303
Network
FCU8-EX56x
J100
SD
FCU8-DX2xx/DX6xx/DX4xx
RIO1
DCIN
J070/071
(EcoMonitor)
OPTH1
OPTH2
J395/J396
J395/J396
EMG
J120
Max. 8 points
J070/071
J070/071
J210
DI:CJ31/33
DO:CJ32/34
RIO1
DCIN
RIO2
DI:CJ31/33
DO:CJ32/34
RIO1
DCIN
RIO2
J350/351
J350/351
J070/071
J070/071
J210
DI:CJ31/33
DO:CJ32/34
RIO1
DCIN
RIO2
DI:CJ31/33
DO:CJ32/34
RIO1
DCIN
RIO2
J350/351
J350/351
(R2-TM)
(R2-TM)
FG
5V:J023/J024/J025
12V:J020/J021/J022
L1 L2
L3
(NFB)
DCOUT
FG
ACIN
CP
MC
ON OFF
MC
MC
J350/351
J350/351
J350/351
J350/351
FCU8-EX54x
EXT1
EXT3
G430
device
Skip signal input
Communication
expansion unit
Control unit
Max. 32 units for each port
Remote I/O unit
Remote I/O unit
Remote I/O unit
Remote I/O unit
24VDC
Energy measuring units
Drive units
Stored in control unit
To the next
remote I/O or
terminator
connector
To the next
remote I/O or
terminator
connector
Emergency
stop switch
SD
memory
card
24VDC24VDC
24VDC24VDC
Machine
control
relay/contact
Machine
control
relay/contact
24VDC
Manual pulse
generator (5V/12V)
Machine operation panel
made by the machine tool builder
Dotted lines indicate the sections prepared by the machine tool builder.
<> Angle brackets indicates attached cable of unit.
No-fuse breaker
24VDC stabilized
power supply
Function
expansion unit
(Note 1)
Handy terminal
FCU8-MU044
RIO4/M
BTBOX
J070/071
DI:CJ31/33
DO:CJ32/34
RIO1
DCIN
RIO2
<J09x>
USB_F
SDC_F
USB_B
SDC_B
<J08x>
FCU8-GC211
RIO3EXT
RS232C
CJ71
FCU8-DX730
CG31
MPG
CG32
NCKB
CG33
CG34
LAN1
J303
Network
LAN2
J303
J210
<G402>
J210
EMG
DCIN
J070/071
LCD
MENUKEY
TP
BL
FRONT
ENC
ON
OFF
CJ71
J010
SIO
FCU8-DX2xx/DX6xx/DX4xx
max. 29 units
J170
<J421>
RIO1
J210
FCU8-KB92x
FCU8-KB941/KB931
<G460>
24VDC
Machine operation panel (Note 2)
24VDC
Remote I/O unit
(Note 3)
Emergency
stop switch
Graphic control unit
device
24VDC
24VDC
Operation panel I/O unit
Menu key
Display unit
Memory mediums
Front memory I/F card
Keyboard unit
(Note 4)
(Note 5)
8.4-type:FCU8-DU121-12
FCU8-KB02x/04x/083
10.4-type:FCU8-DU141-32
15-type:FCU8-DU181-32
