M800W/M80W Series Connection and Setup Manual
3 List of Configuration
17
IB-1501268-K
3.13 Side Memory I/F Unit
3.14 Manual Pulse Generator
3.15 Synchronous Feed Encoder
3.16 Machine Operation Panel
3.17 Handy Terminal
Classification Type Components Remarks
Side Memory I/F Unit FCU8-EP201-2
Side memory I/F PCB
J292 cable
Structural member
SDHC 1ch
USB2.0 1ch
USB communication
(between side memory I/F PCB and personal
computer)
Unit lid (resin molded article), metal plate, etc.
Exclusive for 19-type display unit
Classification Type Components Remarks
5V Manual Pulse Generator UFO-01-2Z9
UFO-01-2Z9
(Produced by NIDEC NEMICON)
Input 5VDC
100pulse/rev
12V Manual Pulse Generator HD60C HD60C
Input 12VDC
25pulse/rev
Classification Type Components Remarks
Synchronous feed encoder OSE1024-3-15-68 OSE1024-3-15-68
Input 5VDC
1024pulse/rev
6000r/min, 68-square flange
Synchronous feed encoder OSE1024-3-15-68-8 OSE1024-3-15-68-8
Input 5VDC
1024pulse/rev
8000r/min ,68-square flange
Synchronous feed encoder OSE1024-3-15-160 OSE1024-3-15-160
Input 5VDC
1024pulse/rev
6000r/min, 160-square flange
Classification Type Components Remarks
Main panel A
(For 8.4-type/15-type display unit)
FCU8-KB921
Escutcheon, key switch
control card
G054 cable, Screw cap set
MITSUBISHI standard key layout (55 keys)
(Standard specification A)
Main panel A
(For 8.4-type/15-type display unit)
FCU8-KB922
Escutcheon, key switch
control card
G054 cable, Screw cap set
Custom specification key layout (55 keys)
(Clear key top cover sold separately)
Main panel B
(For 10.4-type display unit)
FCU8-KB923
Escutcheon, key switch
control card
G054 cable, Screw cap set
MITSUBISHI standard key layout (55 keys)
(Standard specification A)
Main panel B
(For 10.4-type display unit)
FCU8-KB924
Escutcheon, key switch
control card
G054 cable, Screw cap set
Custom specification key layout (55 keys)
(Clear key top cover sold separately)
Main panel A
(For 8.4-type/15-type display unit)
FCU8-KB925
Escutcheon, key switch
control card
G054 cable, Screw cap set
MITSUBISHI standard key layout (55 keys)
(Standard specification B)
Main panel B
(For 10.4-type display unit)
FCU8-KB926
Escutcheon, key switch
control card
G054 cable, Screw cap set
MITSUBISHI standard key layout (55 keys)
(Standard specification B)
Sub panel A
(Common for all display units)
FCU8-KB931
Escutcheon
Emergency stop switch, Override switch
ON/OFF switch, Screw cap set
MITSUBISHI standard switch specification
(Standard specification A)
Sub panel A
(Common for all display units)
FCU8-KB941
Escutcheon
Emergency stop switch, Override switch
ON/OFF switch, Screw cap set
MITSUBISHI standard switch specification
(Standard specification B)
Clear key top set
N030C975G51 /
N030C975G55
Clear key top cover (20 pcs/60 pcs)
Set of labels for M7 standard key layout N939A169G51
Labels for M7 standard key layout (1
sheet)
Classification Type Components Remarks
Handy Terminal
HG1T-SB12UH-
MK1346-L5
