System overview Scope of delivery

SD-/SQ series 2 - 1

2System overview

All devices and system parts belonging to the industrial robots from the MELFA series SD and SQ and

that are required for basic operation of the robot are described in this chapter. Options and spare

parts are listed in the technical manual.

2.1 Scope of delivery

2.1.1 SD series

R001430E

Fig. 2-1: Scope of delivery of robot systems RV-SD and RH-SDH

5-axis articulated arm

SCARA

Fixing screws

(with washers and

snap rings)

Transport locks

Technical documentation

Control unit

Cable set

6-axis articulated arm

Mitsubishi Electric MELFA RV-2SDB Series User Manual
