Handling the control unit Installation
3 - 22
3.4 Handling the control unit
This section describes the handling and set up of the control unit.
3.4.1 Transport control unit CR1DA and drive unit DU1A
3.4.2 Transport control unit CR2DA and drive unit DU2A
E
ATTENTION:
Carry the control unit or drive unit as shown in the illustration below. Lift it by holding firmly
below the front or rear edges. Do not attempt to lift the unit by the switches or connectors.
R001767E
Fig. 3-14: Transport control units CR1DA and drive units DU1A
E
ATTENTION:
Two persons are always required to carry the control unit or the drive unit. To lift, take hold of
the front side and the rear side. Never carry the control unit or the drive unit at their switches or
plug connections.
R001450E
Fig. 3-15: Transport control units CR2DA and drive units DU2A
!
!
