Calibrate the robot system Startup
5 - 4
Error message C0150 is issued the first time you switch on the control unit or the drive unit. In this case,
enter the serial number of the robot arm in the RBSERIAL parameter. The serial number is located on
the type plate on the rear of the robot arm.
Press the [RESET] key on the Teaching Box to reset the error.
Then press the [EXE] key. The main menu appears.
Press key [3] to call up the parameter menu.
Enter "RBSERIAL" in the "NAME" box.
Press the key for "DATA" [F1] and enter the serial number of the robot arm. Press the [EXE] key to
confirm the entry. A beep is issued and the value is stored.
Step 3: Enter the serial number
R001831E
R001832E
R001472E
R001473E
MELFA RV-3SD Ver. 1.0
CRnD-7xx
COPYRIGHT (C) 2007 MITSUBISHI ELEC
TRIC CORPORATION ALL RIGHTS RESE
RVED
<MENU>
1.FILE/EDIT 2.RUN
3.PARAM. 4.ORIGIN/BRK
5.SET/INIT. 6.ENHANCED
CLOSE
123
<MENU>
1.FI LE/EDIT 2.RUN
3.PARAM. 4.ORIGIN/BRK
5.SET/INIT. 6.ENHANCED
CLOSE
123
<PARAMETER> NAME( )
ELE( )
DATA
( )
CLOSE
123
Next
DATA
Prev
<PARAMETER> NAME( )
ELE( )
DATA
()
CLOSE
Next
DATA
Prev
<PARAMETER> NAME(RBSERIAL )
ELE( )
DATA
()
CLOSE
Next
DATA
Prev
ABC ABC
<PARAMETER> (RBSERIAL ) ( )
xxxxxxxޓ
CLOSE
123
Next
DATA
Prev
<PARAMETER> NAME(RBSERIAL )
ELE( )
DATA
(ޓޓޓޓޓޓޓޓޓޓޓޓޓ ޓޓ)
CLOSE
123
Next
DATA
Prev
