FX3U-4AD/FX3UC-4AD (4-channel Analog Input)
6. Changing Input Characteristics
For the 4AD, the standard input characteristics are provided for each input mode (BFM#0) at the time of
factory shipment.
Changing the offset data (BFM#41 to #44) or gain data (BFM#51 to #54), however, can change the input
characteristics of each channel. This chapter describes how to change the input characteristics.
6.1 Procedure for Changing Input Characteristics
1 Determine the input mode (BFM#0)
Determine the optimum input mode (BFM#0) for the selected channels and the voltage/current
specifications.
Example: Enter "HFF00" in BFM#0 to set input mode 0 for channels 1 and 2 and prevent use channels 3 and
4.
Caution regarding data setting:
• If a channel is set to the value "2", "5", "8" or "F", the input characteristics of the channel cannot be
changed.
• Set the optimum input mode for the analog signal to be input.
Set value
(HEX)
Input mode Analog input range Digital output range
0 Voltage input mode -10V to +10V -32000 to +32000
1 Voltage input mode -10V to +10V -4000 to +4000
2
Voltage input analog value direct indication
mode
The offset and the gain cannot be adjusted.
3 Current input mode 4mA to 20mA 0 to 16000
4 Current input mode 4mA to 20mA 0 to 4000
5
Current input analog value direct indication
mode
The offset and the gain cannot be adjusted.
6 Current input mode -20mA to +20mA -16000 to +16000
7 Current input mode -20mA to +20mA -4000 to +4000
8
Current input analog value direct indication
mode
The offset and the gain cannot be adjusted.
9 to E Not used. - -
F Channel not used - -
