5 - 12
CHAPTER5 MEMORIES AND FILES USED FOR CPU MODULE
1
2
3
4
5
6
7
8
5.1 Memories Used for Basic Model QCPU
5.1.5 Operating and writing programs in the standard ROM (boot operation)
(e) Writing a file from GX Developer in another station via CC-Link
Since writing a file to the standard ROM takes time, make the CPU monitoring time setting (SW0A) of CC-Link
to 180 seconds or longer.
For settings of the communication time check period and CPU monitoring time, refer to the following.
GX Developer Version8 Operating Manual
Figure 5.12 Writing a file from GX Developer in another station (via CC-Link)
GX Developer in another station
CPU module that writes
files to the standard ROM
To Next Page
