Mitsubishi 00JCPU User Manual

11 - 12
11.2.4 Procedure for Writing Multiple Programs
This section describes a procedure for writing multiple programs to the program memory. ( Section 5.2.2)
Follow the procedure below and then the procedure provided in Section 11.2.5 before storing the programs in the
memory card for boot operation.
In the following procedure, indicates an operation on the CPU module side.
YES
NO
NO
YES
1)
Ladder (writing) screen
GX Developer Version 8 Operating Manual
GX Developer Version 8 Operating Manual
Use the initial device value?
Set the device memory.
Set the initial device value range.
Set a file name for initial device value in the
PLC file tab of the PLC parameter dialog box.
Start
Start GX Developer.
Set the project.
Change the number of
device points?
Change the number of device points in the
Device tab of the PLC parameter dialog box.
Create a program to be executed
in the CPU module.
Section 6.25
Section 6.25
Section 6.25
