9 - 86
CHAPTER9 DEVICES
9
9.10 Interrupt Pointer (I) 9.10.1 List of interrupt pointer numbers and interrupt factors
9.10.1List of interrupt pointer numbers and interrupt factors
The list of interrupt pointer numbers and interrupt factors are shown below.
(1) Basic model QCPU
*1: The time-limit value of the internal timer is set by default.
In the PLC system tab of the PLC parameter dialog box, the value can be changed within the range of 2ms to 1000ms in increments of
1ms.
*2: To use the intelligent function module interrupt, the intelligent function module setting (interrupt pointer setting) is required in the PLC
system tab of the PLC parameter dialog box. (For interrupt from an intelligent function module, refer to Section 6.23.)
*3: I50 has the highest priority (priority 21), and I127 has the lowest priority (priority 98).
Table9.14 List of interrupt pointer numbers and interrupt factors (Basic model QCPU)
I No. Interrupt factor Priority
I0
Interrupt by interrupt module (QI60)
1st point 5
I1 2nd point 6
I2 3rd point 7
I3 4th point 8
I4 5th point 9
I5 6th point 10
I6 7th point 11
I7 8th point 12
I8 9th point 13
I9 10th point 14
I10 11th point 15
I11 12th point 16
I12 13th point 17
I13 14th point 18
I14 15th point 19
I15 16th point 20
I16 to I27 N/A
I28
Interrupt by internal timer
*1
100ms 4
I29 40ms 3
I30 20ms 2
I31 10ms 1
I32 to I49 N/A
I50 to I127
*2 *3
Intelligent function module interrupt/Interrupt
by interrupt module (QI60)
Specify the intelligent function module
or interrupt module (QI60) with a
parameter.
21 to 98
