(2) High Performance model QCPU
(a) When a Q series interrupt module is mounted
Table9.15 List of interrupt pointer numbers and interrupt factors (High Performance model QCPU)
I No. Interrupt factor Priority I No. Interrupt factor Priority
I0
Interrupt by interrupt
module (QI60)
1st point
2 to 223
I32
*5
Interrupt by an
error
*5 *6
All of stop errors
1
I1 2nd point I33
SINGLE PS. DOWN
*3 *4
I2 3rd point
I34
UNIT VERIFY ERR.,
FUSE BREAK OFF,
SP. UNIT ERROR,
MULTI CPU ERROR
I3 4th point
I4 5th point
I5 6th point
I35
OPERATION ERROR,
SFCP OPE. ERROR,
SFCP EXE. ERROR,
EX.POWER OFF
I6 7th point
I7 8th point
I8 9th point
I9 10th point
I36
ICM. OPE ERROR,
FILE OPE. ERROR
I10 11th point
I11 12th point I37 Empty
I12 13th point I38 PRG. TIME OVER
I13 14th point
I39
CHK instruction
execution,
annunciator detection
I14 15th point
I15 16th point
I40 to
48
Empty
I16
Interrupt by a
sequence-started
module
*1
1st module 224
I17 2nd module 225
I49
Interrupt by
internal timer
0.2ms to 1ms
*7
*10
I18 3rd module 226
I19 4th module 227
I50 to
255
Intelligent
function module
interrupt
*8 *9
Specify the intelligent
function module or
interrupt module (QI60)
with a parameter.
2 to 223
I20 5th module 228
I21 6th module 229
I22 7th module 230
I23 8th module 231
I24 9th module 232
I25 10th module 233
I26 11th module 234
I27 12th module 235
I28
Interrupt by
internal timer
*2
100ms 239
I29 40ms 238
I30 20ms 237
I31 10ms 236
