9.7.4 Registration procedure for the file register
To use a file register, register the file of the file register to the CPU module in the following steps.Note10
Figure 9.74 Registration procedure for the file register
Note10
PLC file tab of the
PLC parameter dialog box
File register setting
Device memory screen
When "Use the following file." is selected
Writing a file register file
Write parameters to the CPU module
Write the file register file to the CPU module
Start
When the file is stored in the
standard RAM or SRAM card:
Write to PLC screen
When the file is stored in the Flash card:
Write to PLC (Flash ROM) screen
Setting a file register file
When "Not used" or
"Use the same file names as the program."
is selected
Note9.10
For the Basic model QCPU, this procedure is not required because the file register is automatically registered to the
standard RAM.
