APPX - 1
APPENDICES
Appendix 1 List of Parameter Numbers
Each parameter number will be stored in the special register (SD16 to SD26) when an error occurs in the parameter
settings.
TableAPPX.1 lists the parameter items and corresponding parameter numbers.
For explanation of mn, **, M, and N shown in the "Parameter No." column, refer to Section 8.3.
(To the next page)
TableAPPX.1 List of parameter numbers
Item Parameter No. Reference
Label 0000
H
Section 8.1
Comment 0001
H
I/O assignment
Type
0400H Section 4.2.2, Section 8.1
Model name
Points
Start XY (Start I/O number)
Basic setting
Base model name
0401
H Section 4.1.2, Section 8.1
Power model name
Extension cable
Slots
Detailed setting
Error time output mode 0403
H Section 6.8, Section 8.1
I/O response time 0405
H Section 6.7, Section 8.1
Control PLC 0406
H
Section 8.1, QCPU User's Manual
(Multiple CPU System)
Switch setting 0407
H Section 6.10, Section 8.1,
Group No.
05mn
H Section 8.3
0Amn
H Section 8.3
Redundant parameters 0D00
H
Section 8.1, QCPU User's Manual
(Multiple CPU System)
No. of PLC 0E00
H
Section 8.1, QCPU User's Manual
(Multiple CPU System)
Operating mode 0E01
H
I/O sharing when using
Multiple CPUs
All CPUs can read all inputs
0E04
H
All CPUs can read all outputs
Timer limit setting
Low speed
1000
H Section 8.1
High speed
RUN-PAUSE contacts
RUN
1001
H
Section 6.6.1, Section 8.1
PAUSE Section 6.6.2, Section 8.1
Remote reset 1002
H Section 6.6.3, Section 8.1
Output mode at STOP to RUN 1003
H Section 6.4, Section 8.1
Floating point arithmetic processing 1004
H Section 2.4.4, Section 8.1.2
Common pointer No. 1005
H Section 9.9.2, Section 8.1
Points occupied by empty slot 1007
H Section 4.1.1, Section 8.1
Interrupt program/Fixed scan program setting
1008
H
Section 2.2.3, Section 2.3.5,
Section 8.1
System interrupt settings
Interrupt counter start No.
Section 8.1
Fixed scan interval (n: 28 to 31)
Intelligent function module setting (Interrupt pointer setting) 100A
H Section 9.10, Section 8.1
Module synchronization 100C
H Section 8.1
A-PLC 100D
H Section 8.1, Section 10.1.4
