Appendix 1 List of Parameter Numbers
APPENDICES
APPX - 2
(To the next page)
TableAPPX.1 List of parameter numbers (continued)
Item Parameter No. Reference
Use serial communication
100E
H Section 6.24, Section 8.1
Transmission speed
Sum check
Transmission wait time
RUN write setting
System interrupt settings
(High speed interrupt setting)
X input 100F
H
Section 6.22, Section 8.1
Y output 1010
H
Buffer read 1011H
Buffer write 1012H
File register 1100H Section 9.7, Section 8.1
Comment file used in a command 1101
H Section 8.1
Initial Device value 1102
H Section 6.26, Section 8.1
File for local device 1103
H Section 9.13.2, Section 8.1
Device points 2000
H Section 9.1, Section 8.1
Latch (1) start/end 2001
H
Section 3.7, Section 6.3,
Section 8.1
Latch (2) start/end 2002
H
Local device start/end 2003H Section 9.13.2, Section 8.1
WDT (watchdog timer) setting
WDT setting
3000
H
Section 6.16, Section 8.1
Initial execution monitoring time Section 2.3.1, Section 8.1
Error check
Carry out battery check
3001
H
Section 6.17, Section 8.1
Carry out fuse blown check
Verify module
Operating mode when there is
an error
Computation error
3002
H
Expanded command error
Fuse blown
Module verify error
Intelligent module program execution error
File access error
Memory card operation error
External power supply OFF
Constant scanning 3003
H Section 6.2, Section 8.1
Error history 3005
H Section 6.18, Section 8.1
Low-speed program execution time 3006
H Section 2.3.3, Section 8.1
Memory check Check Program memory 3008
H Section 6.27, Section 8.1
Detailed setting H/W error time PLC operation mode 4004
H Section 6.9, Section 8.1
Number of modules on MELSECNET/H 5000
H
Section 8.3
Valid module during other station access 5001
H
Interlink transmission parameters 5002H
Routing parameters 5003H
Starting I/O No.
5NM0
HNetwork No.
Total stations
Mode 5NM0
H
