5 - 50
CHAPTER5 MEMORIES AND FILES USED FOR CPU MODULE
1
2
3
4
5
6
7
8
5.4 File Operations by GX Developer and Handling Precautions 5.4.4 Units of file sizes
2) Calculation of program size
The program size is found by the formula: sequence program size + reserved area for online change.
Since files are stored in units of file sizes to the program memory, the parameter file size is 525 steps + 500
steps = 1025 steps. However, the file occupies 1536 steps/6144 bytes.
3) Result
The calculation results of the memory capacities are as shown below.
Figure 5.42 Occupation in units of the file size (program file)
Table5.16 Calculation results of memory capacities
File name File size Memory capacity
PARAM.QPA 564 bytes 512 steps (2048 bytes)
MAIN.QPG
Sequence program size 525 steps
1536 steps (6144 bytes)
Reserved area for online
change
500 steps
Total 1025 steps
Total memory capacity 2048 steps (8192 bytes)
<In program memory>
Sequence
program
Sequence
program
Reserved
area for online
change
Reserved
area for online
change
The parameter file
occupies1536 steps
(6144 bytes).
525 steps
500 steps
