Mitsubishi 00JCPU User Manual

9 - 22
CHAPTER9 DEVICES
9
9.2 Internal User Devices 9.2.7 Link relay (B)
(3) Using the link relay in the network system
Network parameters must be set.
The link relay range areas that is not set by network parameters (not used for a network system such as a
MELSECNET/H network) can be used as the internal relay or latch relay.
• Link relay range where no latch is performed
Internal relay
• Link relay range where latch is performed Latch relay
• Although the points for the link relay in a CC-Link IE Controller Network module is 32768, the default for the link
relay in the CPU module is 8192 points.
• Although the points for the link relay in a MELSECNET/H network module is 16384, the default for the link relay in
the CPU module is 8192 points.
To use the link relay exceeding the above points, change the link relay points in the Device tab of the PLC parameter dialog
box.
Remark
For network parameters, refer to the following.
Manual for each network module
