FX Series PLC User's Manual - Data Communication Edition
Computer Link
3 System Configuration and Equipment Selection
3.2 Applicable FX PLC and Communication Equipment
FX3G
(14-point, 24-point
type)
15 m
(49' 2")
15 m
(49' 2")
FX
3G
(40-point, 60-point
type)
When using channel 1 (ch 1)
The communication equipment works as ch1 when connected to
the option connector 1.
15 m
(49' 2")
15 m
(49' 2")
When using channel 2 (ch 2)
The communication equipment works as ch2 when connected to
the option connector 2.
15 m
(49' 2")
Ch2 is not available when the variable analog potentiometer
expansion board is connected to the option connector 2.
15 m
(49' 2")
FX Series Communication equipment (option)
Total extension
distance
Check
(9-pin D-Sub, male)
FX
3G-232-BD
FX3G-CNV-ADP
FX
3U-232ADP(-MB)
(9-pin D-Sub, male)
FX3G
-232-BD
ch1
(9-pin D-Sub, male)
FX
3G
-CNV-ADP FX
3U
-232ADP(-MB)
(9-pin D-Sub, male)
FX
3G
-232-BD
(9-pin D-Sub, male)
FX
3G-CNV-ADP FX3U- ADP(-MB) FX3U-232ADP(-MB)
(9-pin D-Sub, male)
(Where represents
232 and 485).
