Mitsubishi FX3U-422-BD - For Communication in Accordance with RS-485

D-22
FX Series PLC User's Manual - Data Communication Edition
Computer Link
3 System Configuration and Equipment Selection
3.2 Applicable FX PLC and Communication Equipment
3.2.2 For communication in accordance with RS-485.
FX Series Communication equipment (option)
Total extension
distance
Check
FX
0N
500 m
(1640' 5")
FX
1S
50 m
(164' 0")
500 m
(1640' 5")
FX
1N
50 m
(164' 0")
500 m
(1640' 5")
FX
2N
50 m
(164' 0")
500 m
(1640' 5")
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)
FX 1N -485-BD
(European terminal block)
FX 1N -CNV-BD
+
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)
FX 1N -CNV-BD
+
FX 1N -485-BD
(European terminal block)
FX 1N -CNV-BD
+
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)
FX 1N -CNV-BD
+
FX 2N -485-BD
FX 2N -CNV-BD
+
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)
FX 2N -CNV-BD
+
