REASSEMBLY OF BASIC ENGINE
7-8
1.11 Installing oil screen
(1)
Turn the engine upside-down so that the oil pan
mounting surface is facing up.
(2) Install the oil screen so that the tip of the screen does
not contact the oil pan.
Installing oil screen
1.12 Installing oil pan
(1)
Install new oil pan gasket.
(2) Tighten oil pan bolts evenly and diagonally.
Installing oil pan
