FUEL SYSTEM
8-19
2.6 Disassembling and inspecting governor cover
Disassembling and inspecting governor cover
Disassembling sequence
2.7 Reassembling governor cover
Reassembling governor cover
1 Set bolt 4 Stop lever 7 Lever
2 Set bolt 5 Return spring 8 Governor lever
3 Jam nut 6 Grooved pin






Fatigue and crack
Replace: O-ring


